| In stock: | No | Authentication: | CE ISO |
| Brand: | Wuxi Yinyan | Application: | Chemicals |
| Material Type: | Medium to high viscosity, pasty material | Applicable materials: | Adhesives, Sealants, etc. |
| Power Type: | Electric | How it works: | Convection Mixer |
| Barrel movement: | 3D | Structure: | Planetary Mixer |
| Product Type: | New | Layout form: | Vertical |
| Charge Amount: | 1500L | Amount of processing per time: | 501-1000 |
| Production Capacity: | Custom 2-1500L | Dimensions (L*W*H): | In kind prevail |
| Whole weight: | 1100kg | Discharge method: | Hydraulic |
| Model: | Sxjb | Specifications: | High Viscosity Mixer |
| Trademark: | Silver Swallow | Packaging: | Wooden box or simple packaging |
| Custom Service: | Customize on demand | After-sales service: | Lifetime After Sales |
| Yield: | 500 |
"Double Planetary Power Mixer Adhesive Mixer Sealant Mixer" Details
The working principle of the double planetary power mixer
The double planetary power mixer is equipped with low-speed stirring parts and high-speed dispersing parts. The low-speed stirring parts are driven by planetary gears. And around the movement, so as to achieve the ideal mixing effect in a short time. The high-speed dispersing part revolves together with the planet carrier, and at the same time rotates at a high speed, the material is subjected to strong shearing and dispersing mixing, and its effect is several times that of ordinary mixers. The dispersing parts are divided into single dispersing shaft and double dispersing shaft, which can be selected according to customer needs. The two double-frame agitators revolve and rotate at the same time in the barrel, which can realize vacuuming, heating, cooling, and adjust the speed according to the situation. With multiple mixing barrels, one machine can operate with multiple barrels. Matching the pressing machine makes the material easy to discharge. .
Applicable scope of double planetary power mixer
1. Energy: various battery slurries and pastes (lithium batteries, nickel-chromium batteries, nickel-metal hydride batteries, fuel cells, power batteries, etc.);
span>Second, electronic appliances: solder paste, ceramic paste, magnetic material, silicone ink, electronic adhesive, pvc plastic, electronic and electrical device potting glue, hot melt adhesive , various precious metal powders and slurries;
Third, chemicals:
Various sealants, adhesives (silicone sealants, polysulfide sealants, insulating glass sealants, waterproof sealants, structural sealants, anaerobic adhesives, Stone glue, mold glue, etc.), synthetic resin rubber, ink, putty, abrasive (paste), wax products, synthetic rubber, synthetic resin, various powder materials, ceramic pigments;
4. Medicines: various ointments, polymer gels (medical patches, antipyretic patches for children, cold patches, ice patches, eye patches), Dental products;
5. Cosmetics, daily chemicals: moisturizing cream, lipstick, lotion, gel, mask, mascara, foundation, nail polish, toothpaste, soap.
6. Food: various pastes, paste-like mixtures, seasonings, jams, chocolate syrups.
