| In stock: | No | Authentication: | CE ISO |
| Brand: | Silver Swallow | Application: | Chemicals |
| Material Type: | Medium to high viscosity, pasty material | Applicable materials: | Adhesive |
| Power Type: | Electric | How it works: | Convection Mixer |
| Barrel movement: | 3D | Structure: | Planetary Mixer |
| Product Type: | New | Layout form: | Vertical |
| Charge Amount: | 50 | Amount of processing per time: | 2-50 |
| Production Capacity: | Customize on demand | Dimensions (L*W*H): | In kind prevail |
| Whole weight: | 900KG | Discharge method: | Hydraulic |
| Model: | SXJB | Specifications: | Non-standard mixing equipment |
| Trademark: | Silver Swallow | Packaging: | Wooden Box |
| After-sales service: | Lifetime After Sales | Yield: | 1000 |
"Lab Adhesive Mixer, Small Adhesive Planetary Mixer" Details
Lab Adhesive Mixer:
1. The laboratory planetary power mixer is a multi-functional, mandatory mixer. It usually adopts the mode that the frame, the cylinder head and the stirring blade are lifted and lowered, and the material cylinder is moved.
2. The equipment is sealed, which can be pressurized or vacuumed to remove air bubbles, etc.
3. The kettle body can be heated by electricity, steam, water and oil circulation. The temperature detection device on the drive shaft ensures that the temperature error of the material is less than ±1°C, and the jacket, bottom jacket
jacket, inner coil tube and guide plate in the jacket can be cooled;
4. The inner wall of the kettle is a large vertical Car finishing, and then automatically polished by a large polishing machine to ensure that the movable scraping wall (suitable for sealant) on the planet carrier completely scrapes off the material on the inner wall of the kettle when it rotates;
5. Twist frame in the kettle Type (paddle-to-paddle, paddle-to-bucket wall spacing 3-4mm) stirring paddle (multi-blade), which rotates at the same time as it revolves, making the material flow up and down and around, so that mixing (kneading) can be achieved in a very short time. Effect;
6. The dispersing disc and stirring paddle in the kettle realize the planetary motion of both revolution and rotation. The speed can be adjusted with frequency and variable speed, and different speeds can be selected according to different processes and different viscosities.
Customized adhesive planetary mixer:
Select different stirring forms according to different material viscosity and production process. Common stirring forms include paddle type, twist type, claw type, frame type and other structures, which have good mixing, reaction, kneading and dissolving functions; The high-speed disperser consists of multiple layers of serrated dispersing discs with linear speed. It also revolves around the axis while rotating at high speed, which can quickly disperse powder (auxiliaries) into the slurry, with strong Dispersion; scraper device is selected according to the actual production conditions of customers. During the mixing operation of the double planetary mixer, it is ensured that the mixing is uniform, there is no dead angle and no residue, and the material can be quickly and effectively mixed evenly in a short time.
