| Material: | Other | Type: | Standards |
| Product Specifications: | 6165A6 | Origin: | Japanese Polytechnic |
| Manufacturer (Origin): | Japanese Polytechnic | Processing Level: | Injection Grade |
| Grade: | 6165A6 | Product Name: | PPS |
| import: | No | Brand: | Japanese Polytechnic |
| Usage Level: | Fiber | Sales Method: | Brand Distribution |
| Feature Level: | Flame Retardant |
Detailed introduction of "Supply PPS/Japan Polytechnic/6165A6/Flame Retardant V-0/Dimensional Stability/Polyphenylene Sulfide"
Product parameters Performance item Test condition [state] Test method Test data data unit Basic performance Melt viscosity 310℃, 1000/sec ISO 11443 300 Pa s Water absorption rate 23℃, 24 hours in water ISO 62 0.01 % Density ISO 1183 1.98 g/cm3 Physical Properties Molding shrinkage flow direction 80℃×2mmt 0.2 % Vertical direction 80℃×2mmt 0.5 % Flame retardancy UL 94 V-0 Mechanical properties Bending strength ISO 178 190 MPa Break strain ISO 527-1,2 1.1 % Charpy impact Strength (Notched) ISO 179/1eA 4.5 KJ/m2 Flexural Modulus ISO 178 18300 MPa Tensile Strength ISO 527-1,2 130 MPa Electrical Properties Conductive Track Resistance IEC 60112 200 V Dielectric Constant 1KHz IEC 60250 5.8 Bulk Resistance Rate IEC 60093 8×1015 Ω·cm Surface Resistivity IEC 60093 9×1015 Ω Dielectric Breakdown Strength 1MHz IEC 60250 0.002 Dielectric Breakdown Strength 1KHz IEC 60250 0.002 Dielectric Constant 1MHz IEC 60250 5.8 Dielectric Loss Factor 3mmt IEC 60243 -1 14 kv/mm Thermal Properties Linear Thermal Expansion Coefficient Vertical 2 ×10-5/℃ Linear Thermal Expansion Coefficient Flow Direction ISO 11359-2 1 Load Deformation Temperature 1.8MPa ISO 75-1 270 ℃
